Nginx 反向代理与 SSL 证书配置完整教程 2026

Nginx 反向代理与 SSL 配置

Nginx 是当今最流行的 Web 服务器和反向代理服务器之一，以其高性能、高并发处理能力和低资源消耗著称。本文将带你从基础配置到高级优化，全面掌握 Nginx 的核心技能。

本文涵盖：

✅ 反向代理基础配置
✅ Let's Encrypt SSL 证书自动配置与续期
✅ HTTP/2 与 HTTPS 安全配置
✅ 虚拟主机多域名配置
✅ 负载均衡与健康检查
✅ WebSocket 代理支持
✅ 安全头部与性能优化

一、Nginx 基础安装与配置

1.1 安装 Nginx

bash

# Debian / Ubuntu
sudo apt update && sudo apt install -y nginx

# CentOS / RHEL
sudo dnf install -y nginx

# 验证安装
nginx -v
# 输出示例: nginx version: nginx/1.25.3

# 启动并设置开机自启
sudo systemctl enable --now nginx

# 检查状态
sudo systemctl status nginx

1.2 基础配置文件结构

bash

# Nginx 配置文件结构
/etc/nginx/
├── nginx.conf          # 主配置文件
├── conf.d/             # 额外配置目录
│   └── *.conf          # 站点配置文件
├── sites-available/    # 可用站点配置
│   └── example.com     # 站点配置文件
├── sites-enabled/      # 启用的站点（软链接）
│   └── example.com -> ../sites-available/example.com
└── ssl/                # SSL 证书目录
    ├── example.com.crt
    └── example.com.key

1.3 基础反向代理配置

nginx

# /etc/nginx/sites-available/example.com
server {
    listen 80;
    server_name example.com www.example.com;

    # 重定向到 HTTPS
    return 301 https://$server_name$request_uri;
}

server {
    listen 443 ssl http2;
    server_name example.com www.example.com;

    # SSL 证书配置
    ssl_certificate /etc/nginx/ssl/example.com.crt;
    ssl_certificate_key /etc/nginx/ssl/example.com.key;

    # 反向代理到后端应用
    location / {
        proxy_pass http://localhost:3000;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # WebSocket 支持
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
    }

    # 静态文件直接服务
    location /static/ {
        root /var/www/example.com;
        expires 30d;
        add_header Cache-Control "public, immutable";
    }
}

1.4 启用站点配置

bash

# 创建软链接启用站点
sudo ln -s /etc/nginx/sites-available/example.com /etc/nginx/sites-enabled/

# 测试配置文件语法
sudo nginx -t
# 输出: nginx: configuration file /etc/nginx/nginx.conf test is successful

# 重新加载配置（不中断服务）
sudo systemctl reload nginx

二、Let's Encrypt SSL 证书配置

2.1 安装 Certbot

bash

# 安装 Certbot 和 Nginx 插件
sudo apt update && sudo apt install -y certbot python3-certbot-nginx

# CentOS / RHEL
sudo dnf install -y certbot python3-certbot-nginx

# 验证安装
certbot --version

2.2 自动获取 SSL 证书

bash

# 方法1: 自动配置（推荐）
sudo certbot --nginx -d example.com -d www.example.com

# 方法2: 仅获取证书（手动配置）
sudo certbot certonly --nginx -d example.com -d www.example.com

# 方法3: 手动模式（无服务器）
sudo certbot certonly --manual -d example.com

# 证书文件位置
/etc/letsencrypt/live/example.com/
├── cert.pem          # 证书
├── chain.pem         # 证书链
├── fullchain.pem     # 完整证书链（包含证书和链）
└── privkey.pem       # 私钥

2.3 自动续期配置

bash

# 检查自动续期配置
sudo systemctl status certbot.timer

# 测试续期
sudo certbot renew --dry-run

# 如果需要手动续期
sudo certbot renew

# 强制续期（如果有问题）
sudo certbot renew --force-renewal

# 配置自动续期后重新加载 Nginx
echo "0 3 * * * certbot renew --quiet --deploy-hook 'systemctl reload nginx'" | sudo tee -a /etc/crontab

2.4 完整 SSL 配置示例

nginx

server {
    listen 443 ssl http2;
    server_name example.com www.example.com;

    # SSL 证书
    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;

    # SSL 优化配置
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers HIGH:!aNULL:!MD5;
    ssl_prefer_server_ciphers on;
    ssl_session_cache shared:SSL:10m;
    ssl_session_timeout 10m;
    ssl_stapling on;
    ssl_stapling_verify on;

    # 安全头部
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;
    add_header X-Frame-Options DENY always;
    add_header X-Content-Type-Options nosniff always;
    add_header X-XSS-Protection "1; mode=block" always;
    add_header Referrer-Policy "strict-origin-when-cross-origin" always;

    # 反向代理配置
    location / {
        proxy_pass http://localhost:3000;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
}

三、HTTP/2 配置与性能优化

3.1 HTTP/2 配置

nginx

# 在 server 块中启用 HTTP/2
server {
    listen 443 ssl http2;

    # HTTP/2 优化
    http2_push_preload on;
    http2_max_concurrent_streams 100;
    http2_idle_timeout 60s;
}

3.2 性能优化配置

nginx

# /etc/nginx/nginx.conf

user www-data;
worker_processes auto;
worker_rlimit_nofile 65535;

events {
    worker_connections 1024;
    multi_accept on;
    use epoll;
}

http {
    # 基础优化
    sendfile on;
    tcp_nopush on;
    tcp_nodelay on;
    keepalive_timeout 65;
    types_hash_max_size 2048;

    # Gzip 压缩
    gzip on;
    gzip_vary on;
    gzip_min_length 1024;
    gzip_proxied any;
    gzip_comp_level 6;
    gzip_types text/plain text/css application/json application/javascript text/xml application/xml application/xml+rss text/javascript;

    # Brotli 压缩（需要编译支持）
    # brotli on;
    # brotli_types text/plain text/css application/json application/javascript text/xml application/xml+rss text/javascript;

    # 缓存控制
    expires 1y;
    add_header Cache-Control "public, immutable";

    # 日志优化
    access_log /var/log/nginx/access.log combined buffer=16k;
    error_log /var/log/nginx/error.log warn;

    # 包含站点配置
    include /etc/nginx/sites-enabled/*;
}

3.3 客户端缓存配置

nginx

server {
    # 静态资源缓存
    location ~* \.(jpg|jpeg|png|gif|ico|svg|webp|css|js|woff|woff2|ttf|eot)$ {
        expires 1y;
        add_header Cache-Control "public, immutable";
        add_header ETag "";

        # 禁止缓存敏感文件
        if ($request_uri ~* "(\.php|\.py|\.sh)$") {
            expires off;
            add_header Cache-Control "no-cache, no-store, must-revalidate";
        }
    }

    # HTML 文件不缓存
    location ~* \.(html|htm)$ {
        expires -1;
        add_header Cache-Control "no-cache, no-store, must-revalidate";
        add_header Pragma "no-cache";
    }
}

四、虚拟主机配置

4.1 多域名配置

nginx

# /etc/nginx/sites-available/example.com
server {
    listen 80;
    server_name example.com www.example.com;
    return 301 https://$server_name$request_uri;
}

server {
    listen 443 ssl http2;
    server_name example.com www.example.com;

    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;

    location / {
        proxy_pass http://localhost:3000;
        proxy_set_header Host $host;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    }
}

# /etc/nginx/sites-available/api.example.com
server {
    listen 80;
    server_name api.example.com;
    return 301 https://$server_name$request_uri;
}

server {
    listen 443 ssl http2;
    server_name api.example.com;

    ssl_certificate /etc/letsencrypt/live/api.example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/api.example.com/privkey.pem;

    location / {
        proxy_pass http://localhost:8000;
        proxy_set_header Host $host;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
}

4.2 泛域名配置

nginx

# 泛域名配置（需要通配符证书）
server {
    listen 80;
    server_name *.example.com;
    return 301 https://$host$request_uri;
}

server {
    listen 443 ssl http2;
    server_name *.example.com;

    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;

    # 根据子域名路由到不同后端
    location / {
        if ($host = "api.example.com") {
            proxy_pass http://localhost:8000;
            break;
        }

        if ($host = "app.example.com") {
            proxy_pass http://localhost:3000;
            break;
        }

        # 默认后端
        proxy_pass http://localhost:8080;
    }
}

4.3 获取泛域名证书

bash

# 使用 DNS 验证获取泛域名证书
sudo certbot certonly \
  --manual \
  --preferred-challenges=dns \
  -d example.com \
  -d *.example.com

五、负载均衡配置

5.1 基础负载均衡

nginx

# /etc/nginx/conf.d/upstream.conf
upstream backend {
    server backend1.example.com:8080;
    server backend2.example.com:8080;
    server backend3.example.com:8080;
}

server {
    listen 443 ssl http2;
    server_name example.com;

    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;

    location / {
        proxy_pass http://backend;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    }
}

5.2 负载均衡策略

nginx

# 轮询（默认）
upstream backend {
    server backend1.example.com;
    server backend2.example.com;
}

# 最小连接数
upstream backend {
    least_conn;
    server backend1.example.com;
    server backend2.example.com;
}

# IP 哈希（同一 IP 始终路由到同一服务器）
upstream backend {
    ip_hash;
    server backend1.example.com;
    server backend2.example.com;
}

# 加权轮询
upstream backend {
    server backend1.example.com weight=3;  # 30% 的流量
    server backend2.example.com weight=7;  # 70% 的流量
}

# 健康检查（需要 nginx-plus 或第三方模块）
upstream backend {
    server backend1.example.com max_fails=3 fail_timeout=30s;
    server backend2.example.com max_fails=3 fail_timeout=30s;

    # nginx-plus 健康检查
    # zone backend 64k;
    # health_check;
}

5.3 备用服务器配置

nginx

upstream backend {
    server backend1.example.com;
    server backend2.example.com;

    # 备用服务器（主服务器都不可用时使用）
    server backup.example.com backup;
}

六、WebSocket 代理配置

6.1 基础 WebSocket 代理

nginx

server {
    listen 443 ssl http2;
    server_name example.com;

    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;

    # WebSocket 代理
    location /ws/ {
        proxy_pass http://localhost:8080;

        # WebSocket 必需的头信息
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";

        # 超时设置
        proxy_connect_timeout 7d;
        proxy_send_timeout 7d;
        proxy_read_timeout 7d;

        # 客户端 IP 传递
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header Host $host;
    }
}

6.2 Socket.IO 代理

nginx

server {
    listen 443 ssl http2;
    server_name example.com;

    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;

    # Socket.IO 代理
    location /socket.io/ {
        proxy_pass http://localhost:3000;

        # WebSocket 支持
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";

        # 长轮询支持
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # 超时设置
        proxy_connect_timeout 7d;
        proxy_send_timeout 7d;
        proxy_read_timeout 7d;

        # 缓冲区设置
        proxy_buffers 8 32k;
        proxy_buffer_size 64k;
    }
}

七、安全配置与防护

7.1 安全头部配置

nginx

server {
    # HSTS（强制 HTTPS）
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains; preload" always;

    # 防止点击劫持
    add_header X-Frame-Options DENY always;

    # MIME 类型嗅探防护
    add_header X-Content-Type-Options nosniff always;

    # XSS 保护
    add_header X-XSS-Protection "1; mode=block" always;

    # 内容安全策略（根据需要调整）
    add_header Content-Security-Policy "default-src 'self'; script-src 'self' 'unsafe-inline' 'unsafe-eval'; style-src 'self' 'unsafe-inline'" always;

    # 权限策略
    add_header Permissions-Policy "geolocation=(), microphone=(), camera=()" always;

    # 引荐来源策略
    add_header Referrer-Policy "strict-origin-when-cross-origin" always;

    # 跨域资源共享
    add_header Access-Control-Allow-Origin "*" always;
    add_header Access-Control-Allow-Methods "GET, POST, PUT, DELETE, OPTIONS" always;
    add_header Access-Control-Allow-Headers "Content-Type, Authorization" always;
}

7.2 限制请求速率

nginx

# 限制单 IP 请求速率
limit_req_zone $binary_remote_addr zone=api:10m rate=10r/s;

server {
    location /api/ {
        # 限制每秒 10 个请求，最多延迟处理 50 个请求
        limit_req zone=api burst=50 nodelay;

        proxy_pass http://localhost:8000;
    }
}

# 限制连接数
limit_conn_zone $binary_remote_addr zone=conn_limit:10m;

server {
    location / {
        # 限制单 IP 最多 10 个并发连接
        limit_conn conn_limit 10;

        proxy_pass http://localhost:3000;
    }
}

7.3 禁止访问敏感文件

nginx

server {
    # 禁止访问隐藏文件
    location ~ /\. {
        deny all;
        access_log off;
        log_not_found off;
    }

    # 禁止访问配置文件
    location ~* (config\.json|config\.yml|\.env|\.git) {
        deny all;
        access_log off;
        log_not_found off;
    }

    # 禁止访问日志文件
    location ~* \.(log|sql|bak)$ {
        deny all;
        access_log off;
        log_not_found off;
    }
}

7.4 允许特定 IP 访问

nginx

server {
    # 仅允许特定 IP 访问管理后台
    location /admin/ {
        allow 192.168.1.0/24;
        allow 10.0.0.0/8;
        deny all;

        proxy_pass http://localhost:3000;
    }
}

八、日志配置与分析

8.1 日志格式配置

nginx

# /etc/nginx/nginx.conf
http {
    # 自定义日志格式
    log_format main '$remote_addr - $remote_user [$time_local] "$request" '
                    '$status $body_bytes_sent "$http_referer" '
                    '"$http_user_agent" "$http_x_forwarded_for" '
                    '$request_time $upstream_response_time';

    log_format json '{ "time": "$time_local", '
                    '"remote_addr": "$remote_addr", '
                    '"remote_user": "$remote_user", '
                    '"request": "$request", '
                    '"status": "$status", '
                    '"body_bytes_sent": "$body_bytes_sent", '
                    '"http_referer": "$http_referer", '
                    '"http_user_agent": "$http_user_agent", '
                    '"request_time": "$request_time" }';

    # 访问日志
    access_log /var/log/nginx/access.log main;

    # 错误日志
    error_log /var/log/nginx/error.log warn;
}

8.2 日志分析示例

bash

# 统计访问最多的页面
awk '{print $7}' /var/log/nginx/access.log | sort | uniq -c | sort -nr | head -10

# 统计状态码分布
awk '{print $9}' /var/log/nginx/access.log | sort | uniq -c | sort -nr

# 统计访问最多的 IP
awk '{print $1}' /var/log/nginx/access.log | sort | uniq -c | sort -nr | head -10

# 查找 4xx 和 5xx 错误
awk '$9 >= 400' /var/log/nginx/access.log | head -20

# 计算平均响应时间
awk '{sum+=$14} END {print "Average response time: " sum/NR "ms"}' /var/log/nginx/access.log

九、常见问题与解决方案

Q1：SSL 证书过期怎么办？

bash

# 检查证书过期时间
openssl x509 -enddate -noout -in /etc/letsencrypt/live/example.com/fullchain.pem

# 手动续期
sudo certbot renew

# 如果续期失败，尝试强制续期
sudo certbot renew --force-renewal

# 检查自动续期定时器
sudo systemctl status certbot.timer

Q2：Nginx 启动失败怎么办？

bash

# 检查配置语法
sudo nginx -t

# 查看错误日志
tail -f /var/log/nginx/error.log

# 检查端口是否被占用
sudo ss -tlnp | grep :80
sudo ss -tlnp | grep :443

# 检查权限问题
ls -la /etc/nginx/ssl/
ls -la /etc/letsencrypt/live/example.com/

Q3：反向代理后获取不到真实客户端 IP？

nginx

# 确保配置了以下头信息
location / {
    proxy_pass http://localhost:3000;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    proxy_set_header X-Forwarded-Proto $scheme;
}

在后端应用中读取 X-Forwarded-For 或 X-Real-IP 头来获取真实客户端 IP。

Q4：WebSocket 连接失败？

nginx

# 确保配置了正确的头信息
location /ws/ {
    proxy_pass http://localhost:8080;
    proxy_http_version 1.1;
    proxy_set_header Upgrade $http_upgrade;
    proxy_set_header Connection "upgrade";
    proxy_set_header Host $host;
}

Q5：如何配置 HTTP/3？

bash

# HTTP/3 需要特殊配置（需要编译支持或使用 nginx-plus）
# 检查是否支持 HTTP/3
nginx -V 2>&1 | grep quic

# 如果支持，配置示例
server {
    listen 443 ssl http2 http3;
    listen [::]:443 ssl http2 http3;

    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;

    # QUIC 配置
    ssl_quic on;
    ssl_prefer_server_ciphers on;
    ssl_protocols TLSv1.3;
}

十、完整配置示例

10.1 生产环境完整配置

nginx

# /etc/nginx/sites-available/example.com

# HTTP -> HTTPS 重定向
server {
    listen 80;
    listen [::]:80;
    server_name example.com www.example.com;

    # ACME 挑战（用于 Let's Encrypt 验证）
    location /.well-known/acme-challenge/ {
        root /var/www/html;
        allow all;
    }

    # 其他请求重定向到 HTTPS
    return 301 https://$server_name$request_uri;
}

# HTTPS 主站点
server {
    listen 443 ssl http2;
    listen [::]:443 ssl http2;
    server_name example.com www.example.com;

    # SSL 配置
    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;

    # SSL 优化
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers HIGH:!aNULL:!MD5;
    ssl_prefer_server_ciphers on;
    ssl_session_cache shared:SSL:10m;
    ssl_session_timeout 10m;
    ssl_stapling on;
    ssl_stapling_verify on;

    # 安全头部
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;
    add_header X-Frame-Options DENY always;
    add_header X-Content-Type-Options nosniff always;
    add_header X-XSS-Protection "1; mode=block" always;
    add_header Referrer-Policy "strict-origin-when-cross-origin" always;

    # 静态文件缓存
    location ~* \.(jpg|jpeg|png|gif|ico|svg|webp|css|js|woff|woff2|ttf|eot)$ {
        root /var/www/example.com;
        expires 1y;
        add_header Cache-Control "public, immutable";
        access_log off;
    }

    # WebSocket 代理
    location /ws/ {
        proxy_pass http://localhost:8080;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_connect_timeout 7d;
        proxy_send_timeout 7d;
        proxy_read_timeout 7d;
    }

    # 主应用代理
    location / {
        proxy_pass http://localhost:3000;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # 缓存控制
        expires -1;
        add_header Cache-Control "no-cache, no-store, must-revalidate";
    }

    # 错误页面
    error_page 404 /404.html;
    error_page 500 502 503 504 /50x.html;

    location = /50x.html {
        root /usr/share/nginx/html;
    }
}

结语

Nginx 是一个功能强大的工具，掌握好它可以为你的网站提供高性能、高安全性的服务。本文涵盖了从基础配置到高级优化的大部分内容，但 Nginx 的能力远不止这些。

推荐学习路径：

掌握基础配置和反向代理
配置 SSL 证书和安全头部
学习负载均衡和健康检查
深入了解性能优化和日志分析

推荐阅读：

🚀 提示： 定期更新 Nginx 和 Certbot，保持你的服务器安全和性能处于最佳状态。

延伸阅读

免责声明

本文仅供技术交流和学习参考。涉及第三方服务的链接可能包含 sponsored 标记，请自行核实服务条款、价格和可用性，并遵守当地法律法规。

Nginx 反向代理与 SSL 证书配置完整教程 2026 ​

一、Nginx 基础安装与配置 ​

1.1 安装 Nginx ​

1.2 基础配置文件结构 ​

1.3 基础反向代理配置 ​

1.4 启用站点配置 ​

二、Let's Encrypt SSL 证书配置 ​

2.1 安装 Certbot ​

2.2 自动获取 SSL 证书 ​

2.3 自动续期配置 ​

2.4 完整 SSL 配置示例 ​

三、HTTP/2 配置与性能优化 ​

3.1 HTTP/2 配置 ​

3.2 性能优化配置 ​

3.3 客户端缓存配置 ​

四、虚拟主机配置 ​

4.1 多域名配置 ​

4.2 泛域名配置 ​

4.3 获取泛域名证书 ​

五、负载均衡配置 ​

5.1 基础负载均衡 ​

5.2 负载均衡策略 ​

5.3 备用服务器配置 ​

六、WebSocket 代理配置 ​

6.1 基础 WebSocket 代理 ​

6.2 Socket.IO 代理 ​

七、安全配置与防护 ​

7.1 安全头部配置 ​

7.2 限制请求速率 ​

7.3 禁止访问敏感文件 ​

7.4 允许特定 IP 访问 ​

八、日志配置与分析 ​

8.1 日志格式配置 ​

8.2 日志分析示例 ​

九、常见问题与解决方案 ​

Q1：SSL 证书过期怎么办？ ​

Q2：Nginx 启动失败怎么办？ ​

Q3：反向代理后获取不到真实客户端 IP？ ​

Q4：WebSocket 连接失败？ ​

Q5：如何配置 HTTP/3？ ​

十、完整配置示例 ​

10.1 生产环境完整配置 ​

结语 ​

延伸阅读 ​

Nginx 反向代理与 SSL 证书配置完整教程 2026

一、Nginx 基础安装与配置

1.1 安装 Nginx

1.2 基础配置文件结构

1.3 基础反向代理配置

1.4 启用站点配置

二、Let's Encrypt SSL 证书配置

2.1 安装 Certbot

2.2 自动获取 SSL 证书

2.3 自动续期配置

2.4 完整 SSL 配置示例

三、HTTP/2 配置与性能优化

3.1 HTTP/2 配置

3.2 性能优化配置

3.3 客户端缓存配置

四、虚拟主机配置

4.1 多域名配置

4.2 泛域名配置

4.3 获取泛域名证书

五、负载均衡配置

5.1 基础负载均衡

5.2 负载均衡策略

5.3 备用服务器配置

六、WebSocket 代理配置

6.1 基础 WebSocket 代理

6.2 Socket.IO 代理

七、安全配置与防护

7.1 安全头部配置

7.2 限制请求速率

7.3 禁止访问敏感文件

7.4 允许特定 IP 访问

八、日志配置与分析

8.1 日志格式配置

8.2 日志分析示例

九、常见问题与解决方案

Q1：SSL 证书过期怎么办？

Q2：Nginx 启动失败怎么办？

Q3：反向代理后获取不到真实客户端 IP？

Q4：WebSocket 连接失败？

Q5：如何配置 HTTP/3？

十、完整配置示例

10.1 生产环境完整配置

结语

延伸阅读
